Simulating outages for local cloud apps with LocalStack Chaos API

Introduction

Regardless of the precautions you take in developing your application and the reliability of cloud providers like AWS, incidents are unavoidable. They can be anything from as large-scale regional outage to as small as a request failing for reasons perhaps unknown. Common examples might include:

• Region-wide outages
• DNS failovers
• Service failures
• Network faults

The key is in building your application in such a way that it handles these situations gracefully. Chaos engineering is an approach that for testing these types of scenarios that can help you build a more resilient application.

Introducing the LocalStack Chaos API

LocalStack’s brand-new Chaos API provide an easy way to implement chaos engineering experiments to test a wide variety of simulated outages and failures within your application safely, without impacting your production users. All the testing scenarios described above can be executed within LocalStack, providing thorough coverage for critical situations in a matter of minutes rather than hours or days.

This blog will walk you through the process of setting up a cloud application on your local machine and leveraging the Chaos API to perform service failures in a local environment while using robust error handling to address and mitigate such issues. Furthermore, we will explore how to shift-left your chaos testing by integrating automated testing directly into your continuous integration workflow.

Prerequisites

• LocalStack Docker image & LOCALSTACK_AUTH_TOKEN
• Docker Compose
• AWS CLI & awslocal wrapper
• Maven 3.8.5 & Java 17
• Python & pytest framework
• cURL

Product Management System with Lambda, API Gateway, and DynamoDB

This demo sets up an HTTP CRUD API functioning as a Product Management System. The components deployed include:

• A DynamoDB table named Products.
• Three Lambda functions:
  • add-product for product addition.
  • get-product for retrieving a product.
• A locally hosted REST API named product-api-gateway.
• API Gateway resource named productApi with additional GET and POST methods.

All resources can be deployed using a LocalStack Init Hook via the init-resources.sh script in the repository. To begin, clone the repository on your local machine:

git clone https://github.com/localstack-samples/sample-chaos-api-serverless.git
cd sample-chaos-api-serverless

Let’s create a Docker Compose configuration for simulating a local outage in the running Product Management System.

Set Up the Docker Compose

To start LocalStack and use the Chaos API, create a new Docker Compose configuration. You can find the official Docker Compose file for starting the LocalStack container in our documentation.

For an extended setup, include the following in your Docker Compose file:

• Include the LOCALSTACK_HOST=localstack environment variable to ensure LocalStack services are accessible from other containers.
• Create the ls_network network to use LocalStack as its DNS server and enable the resolution of the domain name to the LocalStack container (also specify it via LAMBDA_DOCKER_NETWORK environment variable).
• Add a new volume attached to the LocalStack container. This volume holds the init-resources.sh file, which is copied to the LocalStack container and executed when the container is ready.
• Add another volume to copy the built Lambda functions specified as ZIP files during Lambda function creation.
• Optionally, add the LAMBDA_RUNTIME_ENVIRONMENT_TIMEOUT to wait for the runtime environment to start up, which may vary in speed based on your local machine.

The final Docker Compose configuration is as follows (also provided in the repository):

version: "3.9"

services:
  localstack:
    networks:
      - ls_network
    container_name: localstack
    image: localstack/localstack-pro:latest
    ports:
      - "127.0.0.1:4566:4566"
      - "127.0.0.1:4510-4559:4510-4559"
      - "127.0.0.1:443:443"
    environment:
      - DOCKER_HOST=unix:///var/run/docker.sock
      - LOCALSTACK_HOST=localstack
      - LAMBDA_DOCKER_NETWORK=ls_network
      - LOCALSTACK_AUTH_TOKEN=${LOCALSTACK_AUTH_TOKEN:?}
      - LAMBDA_RUNTIME_ENVIRONMENT_TIMEOUT=600
    volumes:
      - "./volume:/var/lib/localstack"
      - "/var/run/docker.sock:/var/run/docker.sock"
      - "./lambda-functions/target/product-lambda.jar:/etc/localstack/init/ready.d/target/product-lambda.jar"
      - "./init-resources.sh:/etc/localstack/init/ready.d/init-resources.sh"

networks:
  ls_network:
    name: ls_network

Deploy the local AWS infrastructure

Before deploying the demo application locally, build the Lambda functions to ensure they can be copied over during Docker Compose startup. Execute the following command:

cd lambda-functions && mvn clean package shade:shade

The built Lambda function is now available at lambda-functions/target/product-lambda.jar. Start the Docker Compose configuration, which automatically creates the local deployment using AWS CLI and the awslocal script inside the LocalStack container:

export LOCALSTACK_AUTH_TOKEN=<your-auth-token>
docker-compose up

Check the Docker Compose logs to verify that LocalStack is running and your local AWS infrastructure is set up correctly. You should see the following output:

localstack  |
localstack  | LocalStack version: 3.6.1.dev20240725091954
localstack  | LocalStack build date: 2024-07-26
localstack  | LocalStack build git hash: d536652
localstack  |
localstack  | 2024-07-26T08:55:12.280  INFO --- [  MainThread] l.p.c.b.licensingv2        : Successfully activated cached license a61ce6c3-2f7f-4a18-bc50-b69184a29a4a:enterprise from /var/lib/localstack/cache/license.json 🔑✅
localstack  | 2024-07-26T08:55:13.680  INFO --- [  MainThread] l.p.c.extensions.platform  : loaded 0 extensions
...
localstack  | 2024-07-26T08:55:21.526  INFO --- [et.reactor-2] localstack.request.aws     : AWS sns.CreateTopic => 200
localstack  | {
localstack  |     "TopicArn": "arn:aws:sns:us-east-1:000000000000:ProductEventsTopic"
localstack  | }
localstack  | 2024-07-26T08:55:21.827  INFO --- [et.reactor-3] localstack.request.aws     : AWS sqs.CreateQueue => 200
localstack  | {
localstack  |     "QueueUrl": "http://sqs.us-east-1.localstack:4566/000000000000/ProductEventsQueue"
localstack  | }

After deployment, use cURL to create a product entity. Execute the following command:

curl --location 'http://12345.execute-api.localhost.localstack.cloud:4566/dev/productApi' \
--header 'Content-Type: application/json' \
--data '{
  "id": "prod-2004",
  "name": "Ultimate Gadget",
  "price": "49.99",
  "description": "The Ultimate Gadget is the perfect tool for tech enthusiasts looking for the next level in gadgetry. Compact, powerful, and loaded with features."
}'

The output should be:

Product added/updated successfully.

You can verify the successful addition by scanning the DynamoDB table:

awslocal dynamodb scan \
    --table-name Products

The output should be:

{
    "Items": [
        {
            "name": {
                "S": "Ultimate Gadget"
            },
            "description": {
                "S": "The Ultimate Gadget is the perfect tool for tech enthusiasts looking for the next level in gadgetry. Compact, powerful, and loaded with features."
            },
            "id": {
                "S": "prod-2004"
            },
            "price": {
                "N": "49.99"
            }
        }
    ],
    "Count": 1,
    "ScannedCount": 1,
    "ConsumedCapacity": null
}

Injecting Chaos in the local infrastructure

You can now use the Chaos API for chaos testing of your locally deployed infrastructure. You can access the Chaos API through the REST API at http://localhost.localstack.cloud:4566/_localstack/chaos/faults, accepting standard HTTP requests.

To create an outage, taking down the DynamoDB table in the us-east-1 region, execute the following command:

curl --location --request POST 'http://localhost.localstack.cloud:4566/_localstack/chaos/faults' \
  --header 'Content-Type: application/json' \
  --data '
  [
    {
      "service": "dynamodb",
      "region": "us-east-1"
    }
  ]'

The output should be:

[{"service": "dynamodb", "region": "us-east-1"}]

This command creates an outage in the locally mocked us-east-1 DynamoDB tables. Verify by scanning the Products table:

awslocal dynamodb scan \
    --table-name Products

The output should be:

An error occurred (ServiceUnavailable) when calling the Scan operation (reached max retries: 2): Operation failed due to a simulated fault

You can verify it in the LocalStack logs:

localstack  | 2024-07-26T09:14:31.250  INFO --- [et.reactor-2] localstack.request.aws     : AWS dynamodb.Scan => 503 (ServiceUnavailable)
localstack  | 2024-07-26T09:14:32.255  INFO --- [et.reactor-0] localstack.request.aws     : AWS dynamodb.Scan => 503 (ServiceUnavailable)
localstack  | 2024-07-26T09:14:34.225  INFO --- [et.reactor-2] localstack.request.aws     : AWS dynamodb.Scan => 503 (ServiceUnavailable)

You can retrieve the current outage configuration using the following GET request:

curl --location --request GET 'http://localhost.localstack.cloud:4566/_localstack/chaos/faults'

The output should be:

[{"service": "dynamodb", "region": "us-east-1"}]

Error handling for the local outage

Now that the experiment is started, the DynamoDB table is inaccessible, resulting in the user being unable to retrieve or create products. The API Gateway will return an Internal Server Error. To prevent this, include proper error handling and a mechanism to prevent data loss during a database outage.

You can add a solution that includes an SNS topic, an SQS queue, and a Lambda function that picks up queued elements and retries the PutItem operation on the DynamoDB table. If DynamoDB is still unavailable, the item will be re-queued. The solution includes:

• A process-product-events Lambda for event processing and DynamoDB writes.
• SNS topic named ProductEventsTopic and SQS queue named ProductEventsQueue.
• Subscription between the SQS queue and the SNS topic.
• Event source mapping between the SQS queue and the process-product-events Lambda function.

Run the following commands to create the necessary resources:

awslocal sns create-topic --name ProductEventsTopic

awslocal sqs create-queue --queue-name ProductEventsQueue

awslocal sqs get-queue-attributes --queue-url http://localhost:4566/000000000000/ProductEventsQueue --attribute-names QueueArn

awslocal sns subscribe \
    --topic-arn arn:aws:sns:us-east-1:000000000000:ProductEventsTopic \
    --protocol sqs \
    --notification-endpoint arn:aws:sqs:us-east-1:000000000000:ProductEventsQueue

awslocal lambda create-function \
  --function-name process-product-events \
  --runtime java17 \
  --handler lambda.DynamoDBWriterLambda::handleRequest \
  --memory-size 1024 \
  --zip-file fileb://lambda-functions/target/product-lambda.jar \
  --region us-east-1 \
  --role arn:aws:iam::000000000000:role/productRole

awslocal lambda create-event-source-mapping \
    --function-name process-product-events \
    --batch-size 10 \
    --event-source-arn arn:aws:sqs:us-east-1:000000000000:ProductEventsQueue

awslocal sqs set-queue-attributes \
    --queue-url http://localhost:4566/000000000000/ProductEventsQueue \
    --attributes VisibilityTimeout=10

Test the solution by executing the following command:

curl --location 'http://12345.execute-api.localhost.localstack.cloud:4566/dev/productApi' \
     --header 'Content-Type: application/json' \
     --data '{
       "id": "prod-1003",
       "name": "Super Widget",
       "price": "29.99",
       "description": "A versatile widget that can be used for a variety of purposes. Durable, reliable, and affordable."
     }'

The output should be:

A DynamoDB error occurred. Message sent to queue.

To stop the outage, send a POST request by using an empty list in the configuration. The following request will clear the current configuration:

curl --location --request POST 'http://localhost.localstack.cloud:4566/_localstack/chaos/faults' \
--header 'Content-Type: application/json' \
--data '[]'

Now, scan the DynamoDB table and verify that the Super Widget item has been inserted:

awslocal dynamodb scan \
    --table-name Products

The output should be:

{
    "Items": [
        {
            "name": {
                "S": "Super Widget"
            },
            ...
            "price": {
                "N": "29.99"
            }
        },
        {
            "name": {
                "S": "Ultimate Gadget"
            },
            ...
            "price": {
                "N": "49.99"
            }
        }
    ],
    "Count": 2,
    "ScannedCount": 2,
    "ConsumedCapacity": null
}

Automating Chaos Experiments using Pytest

You can now implement a straightforward chaos test using pytest to start an outage. The test will:

• Validate the availability of Lambda functions and the DynamoDB table.
• Start a local outage and verify if DynamoDB API calls throw an error.
• Validate the ongoing outage and its appropriate cessation.
• Query the DynamoDB table for new items and assert their presence.

For integration testing, you can use the boto3 and the pytest framework. In a new directory named tests, create a file named test_chaos.py. Add the necessary imports and pytest fixtures:

import pytest
import time
import boto3
import requests

# Replace with your LocalStack endpoint
LOCALSTACK_ENDPOINT = "http://localhost.localstack.cloud:4566"
CHAOS_ENDPOINT = f"{LOCALSTACK_ENDPOINT}/_localstack/chaos/faults"

# Replace with your LocalStack DynamoDB table name
DYNAMODB_TABLE_NAME = "Products"

# Replace with your Lambda function names
LAMBDA_FUNCTIONS = ["add-product", "get-product", "process-product-events"]

@pytest.fixture(scope="module")
def dynamodb_resource():
    return boto3.resource("dynamodb", endpoint_url=LOCALSTACK_ENDPOINT)

@pytest.fixture(scope="module")
def lambda_client():
    return boto3.client("lambda", endpoint_url=LOCALSTACK_ENDPOINT)

Add the following code to perform a simple smoke test ensuring the availability of Lambda functions and the DynamoDB table:

def test_dynamodb_table_exists(dynamodb_resource):
    tables = dynamodb_resource.tables.all()
    table_names = [table.name for table in tables]
    assert DYNAMODB_TABLE_NAME in table_names

def test_lambda_functions_exist(lambda_client):
    functions = lambda_client.list_functions()["Functions"]
    function_names = [func["FunctionName"] for func in functions]
    assert all(func_name in function_names for func_name in LAMBDA_FUNCTIONS)

Next, add the following helper functions to start, check, and stop the DynamoDB outage:

def initiate_dynamodb_outage():
    outage_payload = [{"service": "dynamodb", "region": "us-east-1"}]
    response = requests.post(CHAOS_ENDPOINT, json=outage_payload)
    assert response.ok
    return outage_payload

def check_outage_status(expected_status):
    outage_status = requests.get(CHAOS_ENDPOINT).json()
    assert outage_status == expected_status

def stop_dynamodb_outage():
    response = requests.post(CHAOS_ENDPOINT, json=[])
    assert response.ok
    check_outage_status([])

Now, add the following code to chaos test the locally deployed DynamoDB table:

def test_dynamodb_outage(dynamodb_resource):
    # Initiate DynamoDB outage
    outage_payload = initiate_dynamodb_outage()

    # Make a request to DynamoDB and assert an error
    url = "http://12345.execute-api.localhost.localstack.cloud:4566/dev/productApi"
    headers = {"Content-Type": "application/json"}
    data = {
        "id": "prod-1002",
        "name": "Super Widget",
        "price": "29.99",
        "description": "A versatile widget that can be used for a variety of purposes. Durable, reliable, and affordable.",
    }

    response = requests.post(url, headers=headers, json=data)
    assert "error" in response.text

    # Check if outage is running
    check_outage_status(outage_payload)

    # Stop the outage
    stop_dynamodb_outage()

    # Wait for a few seconds
    # Adding a better retry mechanism is left as an exercise
    time.sleep(60)

    # Query if there are items in DynamoDB table
    table = dynamodb_resource.Table(DYNAMODB_TABLE_NAME)
    response = table.scan()
    items = response["Items"]
    assert any(item["name"] == "Super Widget" for item in items)

Run the test locally using the following command:

pytest -v

The output should be:

collected 3 items

tests/test_outage.py::test_dynamodb_table_exists PASSED                                   [ 33%]
tests/test_outage.py::test_lambda_functions_exist PASSED                                  [ 66%]
tests/test_outage.py::test_dynamodb_outage PASSED                                         [100%]

================================= 3 passed in 71.20s (0:01:11) ==================================

Conclusion

We’ve seen how LocalStack’s Chaos API allowed us to quickly manually simulate a service outage to test our application’s response and then adjust it to handle this type of incident gracefully rather than returning an error to our end user. Using tools like PyTest, we can even leverage this API to create tests within automations that can help us ensure that future updates to our application are resilient to failures and outages.

In the upcoming blog posts, we’ll demonstrate how to perform more complex chaos testing scenarios, such as RDS & Route53 failovers, inject network latency to every API call, and use AWS Resilience Testing Tools such as AWS Fault Injection Service (FIS) locally. Stay tuned for more blogs on how LocalStack is enhancing your chaos engineering experience!

You can find the code in this GitHub repository.
